Samtec has introduced the 100-CM Series 1.0 mm vertical compression-mount board connector for millimeter-wave test and measurement applications from DC to 120 GHz. The solderless design supports field replacement and PCB layout flexibility while alignment grooves and PCB fiducials help position the connector on the landing pad. Performance is specified at VSWR ratios of 1.25:1 from DC to 40 GHz, 1.4:1 from 40 GHz to 110 GHz and 1.6:1 from 110 GHz to 120 GHz.
